PUTF201 Clamp-on Ultrasonic Flow Meter

Features:

● 4 Lines Display Velocity, Flow Rate, Volume And Meter Status.
● Clamp-on Mounted, Unnecessary Pipe Cutting Or Processing Interruption.
● Range -40℃~260℃.
● Built-in Data Storage Is Optional.
● Selecting Temperature Sensor PT1000 To Achieve Thermal Energy Measurement Function.
● Suitable For DN20-DN6000 Flow Measurement By Selecting Different Size Transducers.
● Bi-directional Measurement.

Get More Information

Product Introduction

Launched the innovative TF201 series of clamp-on transit-time ultrasonic flowmeters designed to provide reliable and accurate flow measurement solutions for a wide range of applications. This highly advanced technology uses the principle of time difference to measure the flow of liquids and gases in pipes from the outside without stopping the flow or cutting the pipe.

Installation, calibration and maintenance of the TF201 series are very simple and convenient. The transducer is mounted on the outside of the pipe, eliminating the need for complex installation and reducing the possibility of interference or damage to the pipe. Available in different sizes of sensors, the meter is versatile and can meet different measurement needs, making it an ideal solution for various industries.

In addition, by selecting the thermal energy measurement function, the TF201 series can perform a complete energy analysis to provide users with more comprehensive and accurate data. This feature ensures that the meter can be used in a wider range of applications, from process monitoring to water balance testing and district heating and cooling.

Transmitter

Measuring Principle	Transit-time
Velocity	0.01 – 12 m/s, Bi-directional Measurement
Resolution	0.25mm/s
Repeatability	0.1%
Accuracy	±1.0% R
Response Time	0.5s
Sensitivity	0.003m/s
Damping	0-99s(settable by user )
Suitable Fluid	Clean or tiny amounts of solids, air bubbles liquid, Turbidity <10000 ppm
Power Supply	AC: 85-265V DC: 12-36V/500mA
Installation	Wall Mounted
Protection Class	IP66
Operating Temperature	-40℃ to +75℃
Enclosure Material	Fiberglass
Display	4X8 Chinese Or 4X16 English, Backlit
Measuring Unit	meter, ft, m³, liter, ft³, gallon, barrel etc.
Communication Output	4~20mA, OCT, Relay, RS485 (Modbus-RUT), Data Logger, GPRS
Energy Unit	Unit: GJ, Opt: KWh
Security	Keypad Lockout, System Lockout
Size	4X8 Chinese Or 4X16 English, Backlit
Weight	2.4kg

Transducer

Protection Class	IP67
Fluid Temperature	Std. transducer: -40℃~85℃(Max.120℃) High Temp: -40℃~260℃
Pipe Size	20mm~6000mm
Transducer Size	S 20mm~40mm M 50mm~1000mm L 1000mm~6000mm
Transducer Material	Std. Aluminum alloy, High Temp.(PEEK)
Temperature Sensor	PT1000
Cable Length	Std. 10m (customized)
