PMF Electromagnetic Flow Meter
Electromagnetic Flow Meter
The core of the PMF series is a specialized sensor that uses a magnetic field to determine the flow rate of liquid passing through it. The sensor generates a voltage proportional to the flow rate, which is then converted into a digital signal by the relevant transmitter. These data can be displayed on the device itself or remotely through connected computers or control systems.
The PMF series is easy to install and operate, offering a range of options to meet personal needs, including different sizes, materials, and output signals. This makes it a multifunctional choice for various applications, from water supply and drainage in municipal systems to process control in
chemical and petrochemical plants.
The PMF series electromagnetic flowmeter is a high-quality and reliable solution for measuring and monitoring the flow rate of conductive liquids. With its outstanding accuracy, stability, and durability, it provides a cost-effective method to ensure efficient operation in a range of industrial applications.
| Nominal diameter | DN15～DN2000 |
| Electrode material | 316L, Hb, Hc, Ti, Ta, Pt |
| Power supply | AC：90VAC～260VAC/47Hz～63Hz, power consumption≤20VA DC：16VDC～36VDC, power consumption≤16VA |
| Lining material | CR, PU, FVMQ, F4/PTFE, F46/PFA |
| Electrical conductivity | ≥5μS/cm |
| Accuracy class | ±0.5%R, ±1.0%R |
| Velocity | 0.05m/s～15m/s |
| Fluid temperature | -40℃~70℃ |
| Pressure | 0.6MPa～1.6MPa(depends on pipe size) |
| Type | Integrated or separated(flange connection) |
| Enclosure material | Carbon steel, Stainless steel 304 or 316 |
| Installation | Flange connection |
